Interacting via the terminal

Bourne Again SHell (BASH)

The standard way to interact with Unix is by entering commands in a shell. A shell is a terminal window that accepts text entry at the prompt (in these notes, $). There are many shells available, each of which has its own syntax and unique features. The historical shells are the C shell (csh) and the Bourne shell (sh). The default shell on many BSD Unix systems is the KornShell (ksh). On Linux and (until recently) macOS, the default is bash, the Bourne Again SHell. For licencing reasons, macOS has moved to the Z shell (zsh) as of 10.15 Catalina. Many scripting activities that were once written in shell scripting languages are now often coded in Python, Ruby, or Lua. Still, shell scripting is ubiquitous, and it’s useful to have some familiarity with it.

Unix is organized around a file system whose root-level directory is denoted by a single slash (/). Further levels of subdirectories (what Windows and Macintosh users call folders) are nested. On most flavours of Unix, your personal home directory lives at either /usr/home/$USER or /home/$USER; on macOS, home is /Users/$USER. In this notation, $USER is a variable holding your Unix shortname. To save you keystrokes, the home directory is abbreviated by a tilde (~). The current directory (.) and its immediate parent directory (..) also have convenient shortcuts.


Partial tree diagram of a typical Unix directory structure

The shell maintains a sense of where you are in the file system. Your current location, the current working directory, can be queried using the pwd command. The contents of this directory—typically data files, program files (executables), or other subdirectories—can be inspected by typing ls. The cd command changes the current working directory to a new location that the user provides as an argument. Commands that produce output write their results to the next free line of the terminal.

$ pwd                 # report the current working directory
$ cd /                # change the current working directory to /
$ pwd
$ ls                  # list the contents of the current working directory
bin        sbin
dev        tmp
etc        usr
$ cd ~                # go to the user's home directory
$ pwd
$ cd ..              # go to the current directory's immediate parent
$ pwd
$ cd /usr/home/ksdb

In the example above, text that follows a dollar sign ($) is understood to be user input, typed at the keyboard. The explanatory text has no functional purpose; bash ignores any characters to the right of a hash (#).

Try this on your own

Draw a directory tree that shows the path leading from the root directory to your home.

Everything in your home directory is open to modification, including the directory structure. There are commands to create (mkdir) and delete (rmdir) directories.

$ mkdir test     # create directory /usr/home/ksdb/test
$ ls
$ cd test
$ ls             # there are no contents yet
$ cd ..
$ rmdir test     # delete the empty directory /usr/home/ksdb/test


A path is a chain of slash-separated, nested directory names that is used to specify a location in the file system. A path can be either absolute or relative, meaning that it is expressed in reference to either the root or the current working directory.

$ pwd
/usr/home/ksdb                 # heierarchy of directories separated by a slash
$ mkdir /usr/home/ksdb/fruit   # absolute path
$ mkdir vegetables             # relative path
$ cd fruit
$ touch apples                 # create an empty file /usr/home/ksdb/fruit/apples
$ touch ./oranges              # create an empty file /usr/home/ksdb/fruit/oranges
$ ls
apples    oranges
$ touch ../vegetables/broccoli
$ ls /usr/home/ksdb/vegetables
$ ls ../..                    # inspect the directory two levels up
bin       sbin
dev       tmp
etc       usr

A file name argument that is not preceeded by a complete path (such as apples in the example above) is assumed to be in the current working directory. On the other hand, a command without a path is assumed to be somewhere in the default search path. The default search path is specified as a colon-separated list of directories assigned to the shell variable PATH. When a particular command is issued, each successive directory in PATH is explored in an attempt to find the correct executable. The shell’s default path can be modified by the user.

To run programs of your own, you will have to include the full path to the program file. The standard Unix commands are exempted from this requirement. They correspond to a computer program of the same name and live in one of the bin or sbin directories scattered about the file system. These directories are included in the default search path.

$ whereis pwd
$ whereis mkdir
$ whereis cd
$ echo $PATH
$ echo $PATH | rs -c: . 2
/usr/bin         /bin
/usr/sbin        /sbin
/usr/local/bin   /usr/X11/bin
$ mkdir ~/bin
$ export PATH=$PATH:/usr/home/ksdb/bin
$ echo $PATH | rs -c: . 3
/usr/bin         /bin                 /usr/sbin
/sbin            /usr/local/bin       /usr/X11/bin
/usr/X11R6/bin   /usr/home/ksdb/bin

The symbols | rs -c: . 2 following the second call to echo $PATH cause the colon-separated path list to be reformated into two columns. Recall that ~ is a way of accessing the user’s home directory. So, the example has created a new bin directory within the home directory /usr/home/ksdb. The export command ensures that changes to the path variable are recognized by all running shells. (More than one terminal may be open at a time.) PATH is assigned its old value, accessed with $PATH, with the new directory /usr/home/ksdb/bin tacked onto the end of the list. Changes to the path can be made persistent across terminal sessions by adding export PATH=$PATH:<new search directory> to the .bash_profile file in your home directory.


Command invocations have one of the following forms: command, command option(s), command filename(s), or command option(s) filename(s). The ls command, for example, accommodates all of them; e.g., ls, ls -a -l -F, ls myfile.txt, and ls -s myfile.txt.

$ cd ~
$ ls -a
.               .bash_profile
..              .xinitrc
.bash_history    test
$ ls -aF
./               .bash_profile
../              .xinitrc
.bash_history    test/
$ ls -lF /
drwxr-xr-x@ 40 root     wheel   1360 15 Dec 13:59 bin/
dr-xr-xr-x   2 root     wheel    512  2 Jan 08:53 dev/
lrwxr-xr-x@  1 root     admin     11 22 Jan  2008 etc@ -> private/etc
drwxr-xr-x@ 66 root     wheel   2244 15 Dec 13:59 sbin/
lrwxr-xr-x@  1 root     admin     11 22 Jan  2008 tmp@ -> private/tmp
drwxr-xr-x@ 13 root     wheel    442 29 Feb  2008 usr/
lrwxr-xr-x@  1 root     admin     11 22 Jan  2008 var@ -> private/var

Options typically begin with a hyphen. In the example above, -a instructs the ls command to list all files, even the so-called dot files, which are usually invisible. The option pairs -aF and -lF are shortcuts for -a -F and -l -F. The -F option activates additional formatting in the form of a trailing symbol that identifies the file type: / marks a directory, * an executable (program), and @ a symbolic link (pointer to another file). The -l option gives a verbose listing of all the major file attributes. This information is arranged in seven columns, the first of which indicates the file type (character 1) along with the owner (characters 2–4), group (characters 5–7), and other (characters 8-10) access permissions using single-letter codes.

-----1----- 2- --3---  ---4--  --5-- -----6------ ----7---
drwxr-xr-x@ 40 root     wheel   1360 15 Dec 13:59 bin/
Output format for ls -l




file type and permissions


number of links


owner of file


group owner of file


file size in bytes


time and date last modifed


file name

Permissions determine which users are allowed to view (r), run (x), modify (w), or delete (w) a given file. The owner of a file can alter the permissions using the chmod command. In the above code block, the owner has privileges to modify, view, and run; and the members of the group wheel have privileges to view and run.

File type and permission flags

File Type


(-) regular file

(r) read

(d) directory

(w) write

(x) execute

Unix provides hundreds of useful tools. A brief summary of how to use a particular command (the manual, or man pages) can be displayed by typing man command at the command prompt. More detailed instructions for some programs are provided through the GNU Texinfo system.

$ man pwd
$ man bash
$ info bash

Within the man pages, press the down arrow key or return/enter to scroll down a single line and the space bar or n key to move forward one page. Press the h key to get a help screen with detailed navigation instructions. Press q to quit and return to the shell prompt. Within the Texinfo pages, press ? for a summary of basic commands. Press [ctrl-x][ctrl-c] to quit.

Try this on your own

Check out the “man pages” of a few of the commands listed below.

Common Unix commands




change directory


show the current working directory


make a new directory


remove an empty directory


list a directory’s contents


change file permissions


copy a file


move a file


remove a file


update an existing file’s date stamp; create an empty file


view the contents of a long file page by page


show the beginning of a file


show the end of a file


reshape tabular data


simple calculator


echo arguments to the screen


get instructions for a given command


lexical sort


remove duplicate lines


word count


search through the file heirarchy


pattern finder


the Unix Stream EDitor


a line-based stream editor


can be used to concatenate and/or print files

The last four commands in this list (find, grep, sed, and awk) are extremely powerful programs in their own right. find and grep are used to perform regular pattern matching on files and their contents. sed and awk are rather flexible stream editors that implement programming languages of their own. (A stream is a channel for serial data. For instance, Unix’s standard output stream, stdout, directs text output to the terminal.) awk differs from sed in that it reads files line by line and transforms them in a specified way. Entire books have been devoted to these utilities, and we can’t do them justice in these notes.

Try this on your own

Using the mkdir command, make two directories, parent and child, at the same level of the file system hierarchy. With the touch command, create an empty file inside the child directory. Now move the child directory inside of parent with the mv command. What happens when you try to remove parent without first removing child? What happens when you try to remove child without first removing its contents? Remember that there are two distinct remove commands, one for directories and one for files.

In the above exercise, the error messages visible in the terminal window are sent via stderr, the standard error stream.

Job control

Unix is a multitasking operating system that can run many programs (or jobs) at once. Whenever you type a command into the shell, that command is run until it is completed. The output of that command is dumped to stdout and thus appears in the terminal window. If you do not want a long-running job to commandeer the shell, you have the option of running it in the background. This is accomplished by appending an ampersand (&) to the command. It is also possible to kill ([ctrl-c]) or suspend ([ctrl-z]) a job running in the foreground.

Job Control




suspend the current job


terminate the current job


list all jobs


move a job to the foreground


move a job to the background, as if it had been started with an ampersand (&)


suspend a job


terminate a job


process status


show statistics for all running jobs


set job priority

The simplest way to refer to a job is with the combination of a percent character (%) followed by the job’s number. The symbol pair %+ refers to the current job and %- to the previous job. In any output from the shell or the jobs command, the current job is always flagged with a + and the previous job with a -.

$ ./my-program
[1]+  Stopped           ./my-program
$ ./my-other-program
[2]+  Stopped           ./my-other-program
$ jobs
[1]-  Stopped           ./my-program
[2]+  Stopped           ./my-other-program
$ bg %1
[1]  - Running          ./my-program
$ kill %2
[2]  + Terminated       ./my-other-program
$ ./my-other-program &
[2] 49530
$ jobs
[2]+ Running            ./my-other-program

Jobs can also be referred to using the process identifier (PID) provided by the operating system. This number is the one reported in ps and top; in the block above, my-other-program’s PID is 49530.

Pattern matching

One key advantage that a shell has over graphical file managers is the ability to select files based on pattern matching of the filename—that is, the ability to recognize specific sequences of letters and numbers in a filename. This feature is implemented using special symbols called wildcards.

Common Unix commands




matches zero or more characters


matches exactly one character


matches exactly one character listed


matches exactly one character in the given range

[!abcde] or [^abcde]

matches any one character that is not listed

[!a-e] or ^[a-e]

matches any character that is not in the given range

[[:alpha:]] or [A-Za-z]

matches any alphabetical character

[[:upper:]] or [A-Z]

matches any upper-case alphabetical character

[[:lower:]] or [a-z]

matches any lower-case alphabetical character

[[:alnum:]] or [0-9A-Za-z]

matches any alpha-numeric character

[[:digit:]] or [0-9]

matches any single digit


matches any piece of punctuation


matches exactly one entire word from the comma-separated list

(Linux also supports an extended regular expression format that allows for more complex matching. See man re_format. These can be activated in BASH by setting the extglob shell option with shopt.)

The following four commands illustrate how pattern matching works. The first removes every file from the current directory (since * matches every possible sequence of letters and numbers that could exist in a file name). The second moves all html files that have physics in their name to a directory called html. The third lists all files pic1, pic2 or pic3 that have the file extension jpg, png, or eps. And the fourth copies all files with a single character preceding the .dat extension into the directory specified.

$ rm *
$ mv *physics*.html html
$ ls pic[1-3].{jpg,png,eps}
$ cp ?.dat my-directory
$ vim -p lab1/binomial.{cpp,jl,py,rs}

Each of these actions would be rather tedious to perform via point-and-click with a mouse.

Try this on your own

Write a BASH command that lists the names of all files and directories in the current working directory that do not begin with a vowel.

Since *, ?, and ! (as well as $, <, >, and |, as we shall see shortly) have special meanings, BASH provides access to those characters when they are preceded by a backslash. These are examples of escape sequences. Alternatively, any of these characters can be written directly if they are enclosed in single quotes. All but the excalamation point and dollar sign can be written directly in double quotes.

$ echo \?\!\*\$\<\|\>\\\~
$ echo '?!*$<|>\~'
$ echo "?\!*\$<|>\~"

Spaces also need to be escaped since spaces are the shell’s natural delimiter: i.e., mv initial values.txt backup.txt does not take the file initial values.txt and rename it backup.txt; rather, the shell assumes that initial, values.txt, and backup.txt are three distinct command line arguments (which is an error as mv takes only two). Although it is permitted to create file and directory names that include spaces, this is a bad practice and should be avoided.

$ echo Five spaces:\!\ \ \ \ \ \!
Five spaces:!     !
$ echo "Five spaces:\!     \!"
Five spaces:!     !
$ echo 'Five spaces:!     !'
Five spaces:!     !
$ mkdir "My Favourites"
$ touch "My Favourites/latest updates.txt"
$ ls My\ Favourites/latest\ updates.txt
My Favourites/latest updates.txt

Try this on your own

Execute a command that writes to the screen: Sally said, "Hello!"

Redirection and chaining

In addition to files on disk, Unix provides three special streams that are always available, two of which have been mentioned already: stdin (the keyboard), stdout (the screen), and stderr (error messages output to the screen). These, and any other open files, can be redirected. Redirection simply means capturing output from a file, command, program, script, or even code block within a script and sending it elsewhere. For instance, text entered at the command prompt after the echo command would normally be sent, via the stdout stream, directly to the terminal. It can be redirected, using the characters below, to appear in, say, a text file instead. Such output can also be piped to another command, where it serves as input.








the null stream


redirect stdout to file (overwrite—replace existing file, if any)


redirect stdout to file (append—add new data to the end of an already-existing file)


redirect file to stdin


redirect stderr to file


pipe output of one command to input of another


chain two commands, with the second executed iff the first returns an exit status of zero


chain two commands, with the second executed iff the first returns a nonzero exit status

$( ) or ` `

evaluate expression in place

( )

group commands, evalute in a new subshell

{ }

group commands, evalute in current shell


format input as an argument list

Note that we can redirect stdout and stderr separately:

$ cmd > stdout-file 2> stderr-file

Here, whatever output cmd generates that would normally be sent to the screen (via stdout) is instead redirected (by >) to a file named stdout-file; whatever error messages cmd generates that would normally be sent through the stderr stream to the screen are instead redirected (by 2>) to a second file, stderr-file.

The standard error output and the standard output can also be redirected to a single file:

$ cmd > stdall-file 2>&1

Here, > redirects the stdout output of cmd to a file, stdall-file, and the 2> redirection command sends the stderr output to &1, which is a stand-in for the stdout stream. Thus, the stderr material is sent first to the stdout stream, then to stdall-file, as all standard output is in turn redirected there.

It is also possible to suppress output to stderr entirely.

$ rmdir mydirectory
rmdir: /usr/home/ksdb/mydirectory: Directory not empty
$ rmdir mydirectory 2>&-
$ rmdir mydirectory 2> /dev/null

The first line attempts to remove a directory which is not empty. rmdir sends a warning to the user via stderr. The next two lines redirect the error messages which might appear after executing the command to the null stream (which discards everything it’s fed). Whether or not the error message is suppressed, the command will not execute while the objection exists.

The next few examples illustrate how simple commands can be made to work together to produce complex actions.

$ whoami
$ echo Hello, I am user $(whoami)
Hello, I am user ksdb
$ echo Hello, I am user $(whoami) > file1.txt
$ echo Goodbye > file2.txt
$ cat file1.txt file2.txt
Hello, I am user ksdb
$ echo Overwritten > file1.txt
$ echo Appended >> file2.txt
$ cat file1.txt file2.txt

Note that if standard output is redirected to a file that does not exist yet, the file will be automatically created; the touch command is unnecessary. Recall that cat allows for the reading and concatenation of files; listing multiple files after the cat command, as in the above case, results in their being sent to stdout sequentially.

$ { echo first line; echo second line; echo third line; } > file.txt
$ cat file.txt
first line
second line
third line
$ echo "4+6" | bc
$ echo The sum 5+7 is equal to `echo 5+7 | bc`
The sum 5+7 is equal to 12
$ echo The product 6*2 is equal to $(echo 6*2 | bc)
The product 6*2 is equal to 12

Here, the result of the echo "4+6" command is piped from the standard output stream to serve as input for the basic calculator (bc) command. When 4+6 is entered into the basic calculator, the result is computed. Remember that ` ` and $( ) cause the contents to be evaluated as though they existed in a separate command line; the result is then inserted into the present command line.

$ echo export PATH=$PATH:/usr/home/ksdb/bin >> ~/.bash_profile

Here, we are again reassigning the variable PATH to include not only its present value (accessed by $PATH), but the appended directory path /usr/home/ksdb/bin, as well, and exporting this new value to hold across all shells in operation. The >> redirection command redirects the standard output and appends it to the file following the symbol, in this case, ~/.bash_profile. The tilde refers to your home directory; .bash_profile is a startup script—a type of dot file whose contents are read and executed every time a new terminal shell is opened. Thus, the change to PATH’s value is not only valid for the current session, across all shells, but will be a permanent change, as the export command will be executed every time a terminal is opened.

$ echo I work all day | sed 's/day/night/'
I work all night

Recall that the sed command allows for the modification of data in an input stream. Here, the input is I work all day, redirected from stdout by the pipe character. The particulars of sed can be viewed using the man command; here, the s denotes that a substitution should be performed in the stream: the first item between slashes should be replaced by the second.

In the following example, cat > is used to redirect keyboard input (the stdin stream) to a file. The numbers typed subsequently by the user are sent to this file; [ctrl-d] inserts an end-of-file (EOF) marker, a special character which tells the shell when to stop reading keystrokes.

$ cat > meas.dat
3.52    ## from here ...
3.52    ## ... to here is the recorded input

The following example invokes the awk command, which reads through meas.dat line by line and adds all the values in the first column to a running sum, held by the variable x. The first column of the data file (in this case, the only column) is accessed via $1; this notation is common within data manipulation commands. A counter variable, n, is also kept, and used in the computation of the average after each line is read, sent via > to running_average.dat.

$ awk '{ x += $1; n += 1; print x/n; }' meas.dat > running_average.dat
$ cat running_average.dat
$ awk '{ x += $1; n += 1; print x/n; }' meas.dat | tail -n1
$ cat meas.dat | sort | uniq
$ cat meas.dat | sort | uniq | wc -l

Piping the awk output to the tail command results in the printing of the output’s final line. cat meas.dat | sort | uniq first pipes meas.dat to the sort command, which rearranges the contents in ascending order. This ordered file is then piped to the uniq command, which filters out duplicate values. wc is a word and byte counting utility; the option -l results in the number of lines of input being produced. Hence, we determine that meas.dat contains five unique lines.

BASH offers several features to save you keystrokes. File completion is invoked by the tab key. For example, rather than enter cat running_average.dat in the example above, you could just type cat run[tab] and allow BASH to fill in the rest. Access to the command history is available via the up and down arrow keys. This means that the final command issued above can be achieved with [up-arrow] | wc -l.

Numerical data is often stored in text files using a columnar format. There are a variety of tools that allow you to select and manipulate columns.

$ jot 21 0.00 1.00 | rs 3 7 | tee array.txt | rs -T > arrayT.txt
$ cat array.txt
0.00  0.05  0.10  0.15  0.20  0.25  0.30
0.35  0.40  0.45  0.50  0.55  0.60  0.65
0.70  0.75  0.80  0.85  0.90  0.95  1.00
$ awk '{ print $1 }' arrayT.txt > col1.txt
$ awk '{ print $2 }' arrayT.txt > col2.txt
$ awk '{ print $3 }' arrayT.txt > col3.txt
$ paste col3.txt col2.txt col1.txt
0.70    0.35    0.00
0.75    0.40    0.05
0.80    0.45    0.10
0.85    0.50    0.15
0.90    0.55    0.20
0.95    0.60    0.25
1.00    0.65    0.30
$ echo The sum of the values in column two is \
       $(awk '{ x += $1; } END { print x; }' col2.txt)
The sum of the values in column two is 3.5

Above, jot outputs 21 numbers equally spaced between 0.00 and 1.00. This output is piped to rs, which reshapes the data, organizing it into three rows and seven columns. This output is in turn piped to the tee command, which makes a copy of the output in the file array.txt. A final pipe to the reshaping command reorganizes the data into three columns and seven rows, and > sends this transposed version of the data to arrayT.txt.

The Unix philosphy emphasizes small command line tools with narrow capabilities that can be chained together to produce complex results and behaviours. Input and output takes the form of a text stream, and the output of one program can serve as the input for another using the pipe command (|).

For instance, the following set of instructions lists the dozen most common words appearing in the file katex-math.css

$ tr -cs [:alpha:] '\n' < katex-math.css | sort | uniq -c | sort -rn | head -n 12
   8 katex
   7 right
   7 padding
   6 px
   6 em
   6 display
   4 eqno
   3 size
   3 number
   3 margin
   3 left
   3 font

Now let’s plot the frequency histogram for the 101 most common words in Jane Austen’s Pride and Prejudice, the most downloaded book on Project Gutenberg.

$ curl -k -o Pride-and-Prejudice.txt
$ tr -cs [:alpha:] '\n' < Pride-and-Prejudice.txt | sort | uniq -c | sort -rn > freq-hist.dat
$ head -n5 freq-hist.dat
4218 the
4187 to
3707 of
3503 and
2138 her
$ gnuplot
> set terminal dumb
> set tics out
> unset key
> plot[0:100] "freq-hist.dat" using 0:1 with impulse title ""

         +            +            +           +            +            +
  4500 +-+---------------------------------------------------------------+-+
         |*                                                              |
  4000 +-|*                                                              |-+
         |*                                                              |
  3500 +-|**                                                             |-+
         |**                                                             |
  3000 +-|**                                                             |-+
         |**                                                             |
  2500 +-|**                                                             |-+
         |**                                                             |
         |***                                                            |
  2000 +-|*****                                                          |-+
         |******                                                         |
  1500 +-|*******                                                        |-+
         |************                                                   |
  1000 +-|**************                                                 |-+
         |********************                                           |
   500 +-|***********************************                            |-+
     0 +-+---------------------------------------------------------------+-+
         +            +            +           +            +            +
         0            20           40          60           80          100


Scripts are sequences of commands that are collected in a single file and executed together. Unix scripts begin with the shebang (#!) followed by the complete path name of the script interpreter—in this case #!/bin/bash. Subsequent lines beginning with a hash (#) are ignored and thus provide a way of inserting comments into the script. A script must be flagged as executable (chmod +x) before it can be run.

$ whereis bash
$ cat > square
# let i range over the values one to four
for i in 1 2 3 4
   # pipe i*i to the calculator and assign the result to j
   j=$(echo $i*$i | bc)
   echo $i squared is $j
$ chmod +x square
$ ./square
1 squared is 1
2 squared is 4
3 squared is 9
4 squared is 16
$ ./square | grep 9
3 squared is 9
$ ./square | grep 1
1 squared is 1
4 squared is 16

Remember that grep searches through a file line by line and prints any that contain the pattern specified. Above, i is a BASH variable and $i is its current value. Note that variables in a script are just strings of characters and have no numeric sense—unless they are specifically interpreted as numbers, e.g, by piping to bc or by using the BASH keyword let or BASH’s double-parenthesis environment (()):

$ cat > myscript
let A=$A+1
echo A $A
echo B $B
echo C $C
echo B $B
$ chmod +x myscript
$ ./myscript
A 2
B 1+1
C C+1
B 3

Here is an implementation of a simple counter:

$ cat > files
while (( $i < 12 ))
   echo This is the content of file$i.txt > file$i.txt
   echo Oh, and this too\! >> file$i.txt
   let i=i+1
$ chmod +x files
$ ./files
$ ls
file1.txt       file2.txt       file5.txt       file8.txt
file10.txt      file3.txt       file6.txt       file9.txt
file11.txt      file4.txt       file7.txt       files
file1.txt       file16.txt      file4.txt       file9.txt
$ ls file?.txt
file1.txt       file3.txt       file5.txt       file7.txt       file9.txt
file2.txt       file4.txt       file6.txt       file8.txt
$ ls file1*.txt
file1.txt       file10.txt      file11.txt
$ cat file4.txt
This is the content of file4.txt
Oh, and this too!

A script may read in arguments from the command line, entered on the same line as the executable call separated by spaces. The symbols $1, $2, $3, … refer to the first, second, third … arguments, respectively. The number of arguments passed can be queried with $#. The complete set of arguments is referred to by $* or $@.

$ cat > argc
echo $#
$ chmod +x argc
$ ./argc
$ ./argc this
$ ./argc this is
$ ./argc this is a test
$ cat > bookends
if [[ -z $1 ]]
   echo usage: $0 filename
   exit 1
echo $1:
head -n1 $1
echo .
echo .
tail -n1 $1
$ chmod +x bookends
$ ./bookends
usage: bookends filename
$ cat > fox.txt
      brown fox
    jumped over the
lazy   dog
$ ./bookends fox.txt
lazy   dog


There are many subtleties to the use of quotes in BASH. The backward-style single quotes, located above the [tab] button on the keyboard, are used to evaluate and expression in place.

$ echo `echo 4+7 | bc`

The echo 4+7 | bc has been evaluated in place, then acted upon by the first echo command. The straight-style quotations (located to the left of [return]) come in two varieties. The single quote signifies that everything contained within is pure text, and no replacements are to be made.

$ echo '$PATH'

The double straight quotes are used to signify that the contents are acting as a unit. For instance, double quotations placed around multiple words in the command line of a script invocation allow for them to act as a single argument. Double quotations are also used in conjunction with the echo command to signify blocks of material that are to be echoed. Special characters within double quotes, with the exception of the exclamation mark, need no escape sequences. Unlike with single straight quotes, replacements and actions are carried out within the double quotations.

There’s a subtle difference in how the quoted expressions "$@" and "$*" are expanded. The former is understood to mean "$1" "$2" "$3" ..., and the latter, "$1 $2 $3 ...".

$ cat > quotes

echo ranging over '$@'
for x in $@; do echo " -" $x; done

echo ranging over '$*'
for x in $*; do echo " -" $x; done

echo ranging over '"$@"'
for x in "$@"; do echo " -" $x; done

echo ranging over '"$*"'
for x in "$*"; do echo " -" $x; done
$ chmod +x quotes
$ ./quotes one two "three and a half" four
ranging over $@
 - one
 - two
 - three
 - and
 - a
 - half
 - four
ranging over $*
 - one
 - two
 - three
 - and
 - a
 - half
 - four
ranging over "$@"
 - one
 - two
 - three and a half
 - four
ranging over "$*"
 - one two three and a half four

Indentation in scripts has no effect other than to aid readability. It is also not strictly necessary that all scripts terminate with the exit command; the program will stop when it reaches the end of the script. Sometimes, though, and especially when dealing with control structures, a forced quit may be desired, and may be achieved via an exit or an exit 1 (if an error message is desired to be sent) command placed in the script.


A BASH variable is just a string associated with a name. A variable is assigned with the = operator and recalled from memory with the $ prefix.

$ EXE_PATH=/usr/bin
$ EXE=wc
$ echo $EXE_PATH/$EXE
$ ls -l $EXEPATH/$EXE
-r-xr-xr-x   1 root   wheel        38704 31 May  2008 wc

An alternate brace form ${} is used wherever concatenation might lead to ambiguity about which characters belong to the variable name.

$ NUM=0001
$ FILENAME1=infile-$NUM.xml
$ FILENAME2=outfile${NUM}a.yaml
$ FILENAME3=outfile${NUM}b.json
infile-0001.xml   outfile0001a.yaml  outfile0001b.json

Certain variables are predefined:

$ echo The BASH binary is located in $BASH
BASH is located in /bin/bash
$ echo My home directory is $HOME
$ echo I am currently in directory $PWD
$ echo $RANDOM is a pseudorandom number selected from the range 0-32767
15028 is a pseudorandom number selected from the range 0-32767

The % and # symbols can be used to strip trailing and leading characters, respectively, from a variable’s string value. It’s common to want to remove a file extension or the path prefix.

$ FILENAME=output.dat; echo ${FILENAME%.dat}{.eps,.xml}
output.eps output.xml
$ echo in${FILENAME#out}

Various forms of pattern matching are also possible.

$ PATTERN="L*/debug-?/"
$ FILENAME=L32/debug-A/outfile.dat

The # used in the prefix position can also be used to compute the string length. Subranges of strings are specified with positional indices separated by a colon:

$ VAR="this particular string"
$ echo $VAR is ${#VAR} characters long
this particular string is 22 characters long
$ echo T${VAR:1:4} S${VAR:17}
This String

Note that the range is exclusive of the value beginning the interval and inclusive of the last. If no end bracket is specified, the remainder of the string is printed.

$ cat > var

echo $FILENAME1 "-->" $FILENAME2 "-->" ${FILENAME1/config/output}
ROOTNAME=${FILENAME1%.xml} #remove '.xml' from 'config-0027.xml'
COUNT=${ROOTNAME#config-} #remove 'config-' from 'config-0027'
echo The file number is $COUNT
$ chmod +x var
$ ./var
config-0027.xml --> config-0027.dat --> output-0027.dat
The file number is 0027

The arrow text, -->, is quoted to prevent > from being interpreted as the redirection operator.

Array variables can be assigned with multiple space-separated elements enclosed in parentheses. Both the full array and the individual elements are accessible via the ${[]} notation.

$ cat > arrayscript

A=( zero one two three four )
echo The array \"${A[*]}\" has ${#A[*]} elements

for (( i=0; i < ${#A[*]}; ++i))
   echo element $i is ${A[i]}
$ chmod +x arrayscript
$ ./arrayscript
The array "zero one two three four" has 5 elements
element 0 is zero
element 1 is one
element 2 is two
element 3 is three
element 4 is four

Remember that the wildcard * refers to every possible combination of text characters, so ${A[*]} conjures up every element of A. Invoking ${A[?]}, on the other hand, would at most return array elements 0–9.

$ cat > order

if (( $# > 0 ))
   { for (( n=0; n<$#; ++n )); do echo ${A[n]}; done } | sort
$ chmod +x order
$ ./order apple car soda bottle boy
$ ./order apple car "soda bottle" boy

The example above has a subtle error. Only four of the five words appear, since "soda bottle" was entered as a single argument. The for loop ranges over 0, 1, 2, and 3, since there are only four arguments. The array, however, makes no distinction between apple car "soda bottle" boy and `apple car soda bottle boy, reading five elements either way. Thus, the last element of the array is not echoed.

Try this on your own

The example above is not carefully written. Add quotes to the program so that it correctly outputs the following.

$ ./order apple car "soda bottle" boy
soda bottle

Shell arithmetic

Bash arithmetic operations are carried out with the $(( )) or $[ ] notation. Arithmetic operations are only valid for integers, and fractional results are rounded. The basic calculator (bc) should be used instead if non-integer values are required.

$ echo 1+1
$ echo $((1+1))
$ echo $[1+1]
$ echo $[4/5]
$ echo 4/5 | bc -l

The operators and their precedence, associativity, and values are the same as in the C language. The following list of operators is grouped into levels of equal-precedence operators and listed in order of decreasing precedence.

BASH operators



var++ var--

variable post-increment and decrement

++var --var

variable pre-increment and decrement

+ -

unary plus and unary minus

! ~

logical and bitwise negation



* / %

multiplication, division, and remainder

+ -

addition and subtraction

<< >>

left and right bitwise shifts

<= >= <``>``


== !=

equality and inequality


bitwise AND


bitwise exclusive OR


bitwise OR


logical AND


logical OR

expr ? expr : expr

conditional operator

= *= /= %= += -= <<= >>= &= ^= |=


Control structures

Bash provides mechanisms for looping (for, while, until) and branching (if and case). The reserved word for has a syntax for ranging over elements.

$ for colour in red green blue; do echo $colour-ish; done
$ cat > under10.bash
for i in 1 2 3 4 5 6 7 8 9
   echo $i
$ chmod +x under10.bash
$ ./under10.bash

The for construction causes everything inside the dodone block to be executed repeatedly (here, nine times) with i taking the values one to nine in turn.

A contiguous range of integer values can be covered as follows.

$ for i in  {-5..10}; do echo $i; done | rs .
-5  -4  -3  -2  -1  0   1   2   3   4   5   6   7   8   9   10

It’s important that the range {} contain no spaces.

The bash for loop also supports a C-like syntax for counting. The following code sums the numbers 1 to 9 and displays all powers of two less than 200.

$ let j=0; for ((i=1;i<10;++i)); do let j+=$i; done; echo $j
$ for (( i=1; i<200; i*=2 )); do echo $i; done

Try this on your own

Write a chain of BASH commands that outputs the dollar amounts $1.00, $1.25, $1.50, …, $9.75 arranged in four columns.

The while keyword executes a code block as long as a specified condition is met.

$ jot 24 | rs 4 | rs -T | tee array.txt
1   7   13  19
2   8   14  20
3   9   15  21
4   10  16  22
5   11  17  23
6   12  18  24
$ cat array.txt | while read a b c d; do echo $c $a; done
13 1
14 2
15 3
16 4
17 5
18 6
$ { while read a b c d; do echo $c $a; done } < array.txt
13 1
14 2
15 3
16 4
17 5
18 6
$ awk '{ print $3, $1}' array.txt
13 1
14 2
15 3
16 4
17 5
18 6

As well as in the above case, where while appears next to a function whose ability to execute determines the longevity of the loop, while can also appear next to a conditional expression, which evaluates to true or false, in double parentheses.

$ cat > inc

let i=0
while (( $i < 5 ))
   echo $i
   let i+=1

for ((j=0; j<5; ++j))
   echo $j
$chmod +x inc
$ ./inc

until is similar to while, but the conditional in double parentheses contains the stopping condition.

$ cat > inc

let i=0
until (( $i = 5 ))
   echo $i
   let i+=1

for ((j=0; j<5; ++j))
   echo $j
$chmod +x inc
$ ./inc

if allows for the conditional execution of a block of code.

if (( $i < 10 ))
   let i=i+1

if and the conditional test are a single statement. The word then is a new command, either appearing on the next line preceded by a semicolon. The block is terminated by fi, the word if written backwards. then and fi are analogous to do and done that appear in the for, while, and until loops. It is possible to have multiple cases covered by additional elif code blocks:

if (( $i = 5 ))
     echo "i is five"
elif (( $i = 6 ))
     echo "i is six"
elif (( $i = 7 ))
     echo "i is seven"
     echo "i is neither five, six, or seven."

A final, default block of code may be specified beneath else.

Looping structures based on for, while, if, and until can be arbitrarily nested:

$ cat > concat
for prefix in A B C
   for suffix in one two three
     echo $prefix$suffix
$ chmod +x concat
$ ./concat

Evaluation of expressions

Within a BASH script, control is often dependent upon a conditional expression. An expression can be purely arithmetic in nature, in which case it should be evaluated in the double-parentheses environment, (( expression )). An expression that is boolean, on the other hand, should be enclosed in double-braces, [[ expression ]].

Multiple tests of the same nature can be combined within one set of brackets with the logical operations ! (negation), && (and—both sub-expressions must be true for the entire expression to evaluate to true), || (or—one or both of the sub-expressions must be true for the entire expression to evaluate to true), and () (to enclose various nested divisions of the expression).

$ cat > frac_arithmetic

for (( i=1; i<=10; ++i ))
   echo 1/$i^2 = `echo "1.0/"$i"^2" | bc -l`
$ chmod +x frac_arithmetic
$ frac_arithmetic
1/1^2 = 1.00000000000000000000
1/2^2 = .25000000000000000000
1/3^2 = .11111111111111111111
1/4^2 = .06250000000000000000
1/5^2 = .04000000000000000000
1/6^2 = .02777777777777777777
1/7^2 = .02040816326530612244
1/8^2 = .01562500000000000000
1/9^2 = .01234567901234567901
1/10^2 = .01000000000000000000
$ cat > arithmetic

let i=i+1
let j=2*$i+7

if (( $i < $j ))
   echo $i "<" $j
elif (( $i == $j ))
   echo $i = $j
   echo $i ">" $j

The [[ ]] environment recognizes the following logical tests:

BASH tests in the [[ ]] environment



-a file

True if file exists

-d file

True if file exists and is a directory

-e file

True if file exists

-f file

True if file exists and is a regular file

-r file

True if file exists and is readable

-s file

True if file exists and has a size greater than zero

-w file

True if file exists and is writable

-x file

True if file exists and is executable

-N file

True if file exists and has been modified since it was last read

file1 -nt file2

True if file1 is newer (according to modification date) than file2, or if file1 exists and file2 does not

file1 -ot file2

True if file1 is older than file2, or if file2 exists and file1 does not

-z string

True if the length of string is zero

-n string

True if the length of string is non-zero

string1 == string2

True if the strings are equal

string1 != string2

True if the strings are not equal

string1 < string2

True if string1 sorts before string2 lexicographically

string1 > string2

True if string1 sorts after string2 lexicographically

arg1 OP arg2

OP is one of -eq, -ne, -lt, -le, -gt, or -ge.

These arithmetic binary operators return true if arg1 is equal to, not equal to, less than, less than or equal to, greater than, or greater than or equal to arg2, respectively. Both arg1 and arg2 must be (positive or negative) integers

$ touch physics.dat
$ cat > logical

if [[ -e physics.dat  ]]
   echo "physics.dat exists"

if [[ -s physics.dat ]]
   echo "physics.dat exists and is not empty"
$ chmod +x logical
physics.dat exists
$ cat > physics.dat
physics.dat exists and is not empty

Beware of seemingly-mathematical comparisons. Within curved parentheses, <, >, and = involve lexical comparisons. For example (( 5 < 16 )) is true, but [[ 5 < 16 ]] is not, since the string 16 comes before the string 5 in standard alphanumeric order. The proper integer comparision is [[ 5 -lt 16 ]].

$ for i in 0 1 2 3 4 5 6 7 8 9; do touch example$i.dat; done
$ ls
example0.dat   example2.dat   example4.dat   example6.dat   example8.dat
example1.dat   example3.dat   example5.dat   example7.dat   example9.dat
$ find . -name "example[^13579].dat"
$ ls example[1-9].dat | xargs -n3 echo
example1.dat   example2.dat   example3.dat
example4.dat   example5.dat   example6.dat
example7.dat   example8.dat   example9.dat
$ ls example?.dat | xargs -n2 echo
example0.dat   example1.dat
example2.dat   example3.dat
example4.dat   example5.dat
example6.dat   example7.dat
example8.dat   example9.dat
$ find . -name "example[12358].dat" -delete
$ ls
example0.dat   example4.dat   example6.dat   example7.dat   example9.dat
$ [[ -e example0.dat ]] && echo file exists
file exists
$ [[ -e example1.dat ]] || echo file does not exist
file does not exist
$ [[ -z $(cat example0.dat) ]] && echo file is empty
file is empty


A function is a block of code that is invoked with its short-hand name followed by zero or more parameters. Parameters are handled in the same way as arguments to a script.

$ cat > fibonnaci

function add {
   if [[ -z $1 || -z $2 ]]
      echo function add requires two arguments >&2
      exit 1
      let sum+=$2
      echo $sum


for (( i=0; i<12; ++i ))
   x2=$(add $x0 $x1)
   echo $x2

$ chmod +x fibonnaci
$ ./fibonnaci | rs 3
1    2    3    5
8    13   21   34
55   89   144  233

Useful idioms

One of the main uses for scripts is batch processing, i.e., launching multiple instances of a program with different initial parameters. Suppose that we have a program myprog1 that takes a command line option --coupling-strength, computes some physical property that depends on the value provided, and reports the answer to the stardard output stream. The following script will run the program for the values 0.0, 0.2, …, 1.0 and store the results in files output-J0.0.dat, output-J0.2.dat, …, output-J1.0.dat, collected in the runs1 directory.

$ cat > batch1


[[ ! -e runs1 ]] && mkdir runs1

for J in `jot 6 0 1.0`
   $EXE --coupling-strength=$J > runs1/output-J$J.dat
$ chmod +x batch1
$ ./batch1
$ ls runs1
output-J0.0.dat  output-J0.2.dat  output-J0.4.dat
output-J0.6.dat  output-J0.8.dat  output-J1.0.dat

Consider another program myprog2 that takes a --lattice-size parameter and dumps its results to a file outfile.dat in the current working directory. The following script organizes the batch execution of myprog2 invoked with various values of --lattice-size stored in runs2/L16, runs2/L20, …, runs2/L48



[[ ! -e runs2 ]] && mkdir runs2

TOP=$PWD # value of the current working directory
for L in 8 16 20 24 32 40 48
   [[ ! -e $DIR ]] && mkdir $DIR && cd $DIR && $EXE --lattice-size=$L
   cd $TOP

Now let’s consider how to collate and process the data. Suppose that each outfile.dat contains a single comment line followed by three columns of data. We can pick out the “magnetization” as follows.

$ head -n5 runs2/L8/outfile.dat
### sample ##### energy ##### magnetization ###
    000000        43.77           697.6
    000001        43.39           967.5
    000002        45.11           928.2
    000003        46.35           928.2
$ awk '{ if (substr($1,0,1) != "#") print $3; }' runs2/L8/outfile.dat

(Note that substr is an awk function that picks out a substring from a string of text.)

Suppose further that we want to summarize the magnetization data in all the runs2 subdirectories in terms of an average and variance for each lattice size. The following script does just that. Note that the calculations have been encapsulated in functions average and variance.


function average {
   awk 'BEGIN { x=0.0; n=0; while(substr($1,0,1) == "#"); } \
              { x += $3; n += 1; } \
          END { print x/n; }' $1

function variance {
   awk 'BEGIN { x=0.0; n=0; while(substr($1,0,1) == "#"); } \
              { x += ($3-'$2')**2; n += 1; } \
          END { print sqrt(x/n); }' $1

rm runs2/mag.dat 2>&-

for L in 8 16 20 24 32 40 48
   if [ -e $FILE ]
       AVE=$(average $DIR/outfile.dat)
      echo $L $AVE $(variance $DIR/outfile.dat $AVE) >> runs2/mag.dat

One drawback to the script above is that the lattice sizes are hard coded. If we perform an additional run for --lattice-size=64, then we have to edit the collection script to include 64 in the for L loop. Here’s another way to write the script that doesn’t require advance knowledge of which L values have already been simulated. It simply ranges over the directories it finds in runs2.


function average {
   awk 'BEGIN { x=0.0; n=0; while(substr($1,0,1) == "#"); } \
              { x += $3; n += 1; } \
          END { print x/n; }' $1

function variance {
   awk 'BEGIN { x=0.0; n=0; while(substr($1,0,1) == "#"); } \
              { x += ($3-'$2')**2; n += 1; } \
          END { print sqrt(x/n); }' $1

rm /tmp/mag.dat 2>&-

for FILE in $(ls -d runs2/L*/outfile.dat)
   AVE=$(average $FILE)
   echo $L $AVE $(variance $FILE $AVE) >> /tmp/mag.dat

sort -n -k1,1 /tmp/mag.dat runs2/mag.dat
rm /tmp/mag.dat 2>&-

This script has one subtlely. The text is initially dumped to a temporary file /tmp/mag.dat which only becomes runs2/mag.dat after it’s sorted. Why is this necessary? (Hint: there is a difference between lexical and numerical order.)

$ mkdir L2
$ mkdir L5
$ mkdir L10
$ mkdir L20
$ mkdir L50
$ mkdir L100
$ ls -d L*
L10   L100   L2   L20   L5   L50
$ for x in $(ls -d L*); do echo ${x:1}; done | rs 1
10   100  2    20   5    50
$ ls -d L* | tr L " " | sort -n | rs 1
2    5    10   20   50   100

We should say a few words about how BASH can be used to automate the production of other scripts.

$ cat > plotter
for FILENAME in "$@"
   echo plot \'$FILENAME\' using 1:2:3 with errorbars
   echo pause -1
$ chmod +x plotter
$ plotter runs1/outfile-J*.dat >
$ gnuplot

It is also possible to perform and visualize simple calculations right from the command line. For instance, the following bash session graphs the trajectory of a particle,

\[\begin{aligned} \mathsf{x(t)} &= \mathsf{x_0} + \mathsf{v_{x,0}t},\\ \mathsf{y(t)} &= \mathsf{y_0} + \mathsf{v_{y,0}t} - \mathsf{\frac{1}{2}gt^2}, \end{aligned}\]

which has been launched from \((\mathsf{x_0, y_0}) = (\mathsf{40,600})\) with initial velocity \((\mathsf{v_{x,0},v_{y,0}}) = (\mathsf{30,30})\).

$ cat > col2ps
echo "%!"
read a b
echo $a $b moveto
while read a b
   echo $a $b lineto
echo 2 setlinewidth
echo stroke
echo showpage
$ chmod +x col2ps
$ jot 131 0.00 13.00 | awk '{ print 40+30*$1, 600+30*$1-0.5*9.8*$1**2 }' - | ./col2ps >
$ gv
$ ps2pdf freefall.pdf
$ magick convert -density 150 -resize 25% -colorspace Gray freefall.png

This is hardly the best way to obtain such a plot, but it’s a cute demonstration of how we can chain together different unix tools to carry out complex tasks.

Try this on your own

Evaluate the oscillating behaviour \(x(t) = \sin(t) + 0.25\sin(2t)\) over the range \(t \in [0,10]\) with \(t\) sampled in steps of \(\Delta t = 0.1\). Output the values to a text file in two-column format.
